Application of tapered roller bearings
Release time:
2023-09-28
Tapered roller bearings have tapered inner and outer raceways, with tapered rollers arranged between them. The projection lines of all conical surfaces converge at the same point on the bearing axis. This design makes tapered roller bearings particularly suitable for bearing composite (radial and axial) loads. The axial load capacity of bearings is mostly determined by the contact angle α Determined; α The larger the angle, the higher the axial load capacity. The angle size is represented by the calculation coefficient e; The larger the e-value, the greater the contact angle, and the greater the applicability of the bearing to withstand axial loads.
Tapered roller bearings mainly bear radial and axial combined loads. The bearing capacity depends on the raceway angle of the outer ring, and the larger the angle, the greater the bearing capacity. This type of bearing belongs to the separated type and is divided into single row, double row, and four row tapered roller bearings based on the number of rows of rolling elements in the bearing. The clearance of single row tapered roller bearings needs to be adjusted by the user during installation; The clearance of double row and four row tapered roller bearings has been given according to user requirements when the product leaves the factory and does not require user adjustment.
Tapered roller bearings have tapered inner and outer raceways, with tapered rollers arranged between them. The projection lines of all conical surfaces converge at the same point on the bearing axis. This design makes tapered roller bearings particularly suitable for bearing composite (radial and axial) loads. The axial load capacity of bearings is mostly determined by the contact angle α Determined; α The larger the angle, the higher the axial load capacity. The angle size is represented by the calculation coefficient e; The larger the e-value, the greater the contact angle, and the greater the applicability of the bearing to withstand axial loads.
Tapered roller bearings are usually of the separated type, that is, the conical inner ring component composed of inner rings with roller and cage components can be installed separately from the conical outer ring (outer ring).
Tapered roller bearings are widely used in industries such as automobiles, rolling mills, mining, metallurgy, and plastic machinery.
